Energy efficiency and design meet perfection
The denser a building envelope, the lower the energy consumption.
However, this does not mean that you have to give up an open and bright design.
FEATURES
| PROFILE WIDTH | 80 mm Compressed Gasket |
|---|---|
| NUMBER OF CHAMBERS | 5 Chambers |
| THERMAL INSULATION | Uf= 1,3 W/m²K |
| THEFT PROTECTION | Up to resistance class (DIN EN 1627) |
| SOUND INSULATION | Up to 43 dB |
| AIR PERMEABILITY | 4th class according to DIN EN 12207 |
| RAIN TIGHTNESS | Class 9A according to DIN EN 12208 |
| RESISTANCE TO WIND LOAD | up to class B3 according to DIN EN 12210 |
ADVANTAGES
- Glass thickness up to 51 mm
- It has a high quality sealing feature to provide a better wearing comfort.
- Insulated HDF- surface for unmatched shine and comfort
- Landscape version for more light penetration
- Components up to 2.70 m high and 10 m wide can be used
- Has a passage width of up to 5 meters
- It is a recyclable, environmentally friendly product.
- It provides excellent energy efficiency.
- It offers excellent comfort with its various application features.
DESIGN
- Provides all unlocking features
- Provides design diversity with KALEIDO COLOR
- Can also be used in conservatories
SCOPE OF APPLICATION
- New buildings and renovated buildings
- It provides a seamless transition from living areas to the balcony, terrace or garden.
- Can also be used in conservatories
